Description
This 20.5in (52.1cm) long USB power splitter cable allows you to charge up to 6 x electronic devices from a single +5VDC USB wall power adapter or other +5VDC USB power source. This power splitter cable has a single regular USB Type-A male plug at one end of the cable and 6 x regular Type-A female sockets at the other end of the cable. This power splitter cable works with our 3-cell (+5VDC) battery eliminator kits and other battery eliminator kit accessories such as our power extension cables and power splitter cables provided they have the appropriate USB connectors or the appropriate USB connector conversion adapters.
Note(s)
One of the six regular Type-A female sockets provides USB 2.0 data transmission (480Mbps) plus +5VDC for charging. The other 5 regular Type-A female sockets do not provide data transmission and only provide +5VDC for charging. The USB connectors with the universal USB symbols provide data transmission plus +5VDC for charging. The other plain black USB connectors with no symbols only provide +5VDC for charging.
Features
· 20.5in (52.1cm) Overall Cable Length
· 10.5in (26.7cm) Regular USB Type-A Male Plug Cable Length
· 10in (25.4cm) 6 x Regular Type-A Female Socket Cable Lengths
· Cable Has a Single Regular USB Type A-Male Plug at One End of the Cable and 6 x Regular Type-A Female Sockets at the Other End of the Cable
· Works With Our 3-Cell (+5VDC) Battery Eliminator Kits and Other Battery Eliminator Kit Accessories Such as Our Power Extension Cables and Power Splitter Cables Provided They Have the Appropriate USB Connectors or the Appropriate USB Connector Conversion Adapters
· Allows for Charging of Up to 6 x Electronic Devices from a Single +5VDC USB Wall Power Adapter or Other +5VDC USB Power Source
Specifications
Manufacturer
Made in China
Manufacturer’s Part Number
1X6-SPLITTER-CABLE-USB
Cable Type
Black, Round Jacketed Cable
Cable Lengths
· 20.5in (52.1cm) Overall Cable Length (End-to-End)
Wire Gauge
Copper, 22AWG Stranded Each Conductor (2A Recommended Maximum)
Connectors
· 1 x Regular USB Type-A Male Plug at One End of Cable
· 6 x Regular Type-A Female Sockets Other End of Cable
Supported Charging Current
· Charging Current Limited by +5VDC USB Charging Source
· 2A Recommended Maximum Current Limited by 22AWG Wire Gauge
· USB 2.0 +5VDC Source Current Limited to 500mA
Supported Data Transmission Rate
· 480Mbps (USB 2.0) – Only Supported by 1 of the 6 Charging Cables (Connector Marked with Universal USB Symbol)
Insulating Materials
· Black PVC Insulation Material
· Black PVC Over-Molded Connectors
Location Rating
Indoor Use Only
Color
Black
